Specifications
| SIZE | PLY RATING |
LOAD RANGE |
LOAD SPEED INDEX | TREAD DEPTH (32NDS) |
MAX LOAD SINGLE (LBS) |
MAX PRESSURE SINGLE (PSI) |
MAX LOAD DUAL (LBS) |
MAX PRESSURE DUAL (PSI) |
APPROVED RIM WIDTH |
O.D. (IN) |
S.W. (IN) |
REVS/MILE | WEIGHT (LBS) |
TREAD CONSTRUCTION |
| 385/65R22.5 | 20PR | L | 160K | 23 | 9920 | 130 | NA | NA | 11.75, 12.25 | 42.2 | 15.3 | 478 | 176 | 1S+4S |
| 425/65R22.5 | 20PR | L | 165K | 23 | 11400 | 120 | NA | NA | 11.75, 12.25, 13.00 | 44.3 | 16.6 | 476 | 202 | 1S+4S |
