Specifications

SIZE PLY
RATING		 LOAD
RANGE		 LOAD SPEED INDEX TREAD DEPTH
(32NDS)		 MAX LOAD
SINGLE
(LBS)		 MAX PRESSURE
SINGLE
(PSI)		 MAX LOAD
DUAL
(LBS)		 MAX PRESSURE
DUAL
(PSI)		 APPROVED
RIM WIDTH		 O.D.
(IN)		 S.W.
(IN)		 REVS/MILE WEIGHT
(LBS)		 TREAD
CONSTRUCTION
11R22.5 14PR G 144/142L 17 6175 105 5840 105 7.50, 8.25 41.5 11.0 486 109 1S+4S
11R22.5 16PR H 146/143L 17 6610 120 6005 120 7.50, 8.25 41.5 11.0 486 109 1S+4S
11R24.5 14PR G 146/143L 17 6610 105 6005 105 7.50, 8.25 43.5 11.0 464 117 1S+4S
11R24.5 16PR H 149/146L 17 7160 120 6610 120 7.50, 8.25 43.5 11.0 464 117 1S+4S
295/75R22.5 14PR G 144/141L 17 6175 110 5675 110 8.25, 9.00 39.9 11.7 505 105 1S+4S
295/75R22.5 16PR H 149/146L 17 7160 125 6610 125 8.25, 9.00 39.9 11.7 505 105 1S+4S
255/70R22.5 16PR H 140/137L 17 5510 120 5070 120 7.50, 8.25 36.6 10.0 551 86 1S+4S
