Specifications
| SIZE | PLY RATING |
LOAD RANGE |
LOAD SPEED INDEX | TREAD DEPTH (32NDS) |
MAX LOAD SINGLE (LBS) |
MAX PRESSURE SINGLE (PSI) |
MAX LOAD DUAL (LBS) |
MAX PRESSURE DUAL (PSI) |
APPROVED RIM WIDTH |
O.D. (IN) |
S.W. (IN) |
REVS/MILE | WEIGHT (LBS) |
TREAD CONSTRUCTION |
| 11R22.5 | 16PR | H | 146/143K | 24 | 6610 | 120 | 6005 | 120 | 7.50, 8.25 | 41.5 | 11.0 | 486 | 121 | 1S+4S |
| 11R24.5 | 16PR | H | 149/146K | 24 | 7160 | 130 | 6610 | 130 | 7.50, 8.25 | 43.5 | 11.0 | 464 | 129 | 1S+4S |
| 255/70R22.5 | 16PR | H | 140/137L | 23 | 5510 | 120 | 5070 | 120 | 7.50, 8.25 | 36.6 | 10.0 | 551 | 94 | 1S+4S |
| 275/70R22.5 | 18PR | J | 148/145K | 23 | 6940 | 130 | 6395 | 130 | 8.25, 9.00 | 37.7 | 10.9 | 535 | 111 | 1S+4S |
| 315/80R22.5 | 20PR | L | 161/157K | 24 | 10000 | 130 | 8270 | 130 | 9.00, 9.75 | 42.4 | 12.3 | 476 | 146 | 1S+4S |
