Specifications
| SIZE | PLY RATING |
LOAD RANGE |
LOAD SPEED INDEX | TREAD DEPTH (32NDS) |
MAX LOAD SINGLE (LBS) |
MAX PRESSURE SINGLE (PSI) |
MAX LOAD DUAL (LBS) |
MAX PRESSURE DUAL (PSI) |
APPROVED RIM WIDTH |
O.D. (IN) |
S.W. (IN) |
REVS/MILE | WEIGHT (LBS) |
TREAD CONSTRUCTION |
| 11R22.5 | 14PR | G | 144/142L | 27 | 6175 | 105 | 5840 | 105 | 7.50, 8.25 | 41.5 | 11.0 | 486 | 122 | 1S+4S |
| 11R22.5 | 16PR | H | 146/143L | 27 | 6610 | 120 | 6005 | 120 | 7.50, 8.25 | 41.5 | 11.0 | 486 | 122 | 1S+4S |
| 11R24.5 | 14PR | G | 146/143L | 27 | 6610 | 105 | 6005 | 105 | 7.50, 8.25 | 43.5 | 11.0 | 464 | 130 | 1S+4S |
| 11R24.5 | 16PR | H | 149/146L | 27 | 7160 | 120 | 6610 | 120 | 7.50, 8.25 | 43.5 | 11.0 | 464 | 130 | 1S+4S |
| 295/75R22.5 | 14PR | G | 144/141L | 28 | 6175 | 110 | 5675 | 110 | 8.25, 9.00 | 40.0 | 11.7 | 505 | 116 | 1S+4S |
| 295/75R22.5 | 16PR | H | 146/143L | 28 | 6610 | 120 | 6005 | 120 | 8.25, 9.00 | 40.0 | 11.7 | 505 | 116 | 1S+4S |
