Specifications

SIZE PLY
RATING		 LOAD
RANGE		 LOAD SPEED INDEX TREAD DEPTH
(32NDS)		 MAX LOAD
SINGLE
(LBS)		 MAX PRESSURE
SINGLE
(PSI)		 MAX LOAD
DUAL
(LBS)		 MAX PRESSURE
DUAL
(PSI)		 APPROVED
RIM WIDTH		 O.D.
(IN)		 S.W.
(IN)		 REVS/MILE WEIGHT
(LBS)		 TREAD
CONSTRUCTION
11R22.5 16PR H 146/143L 28 6610 120 6005 120 7.50, 8.25 41.5 11.0 486 130 1S + 4S
11R24.5 16PR H 149/146L 28 7160 120 6610 120 7.50, 8.25 43.5 11.0 464 140 1S + 4S
225/70R19.5 14PR G 128/126N 22 3965 110 3745 110 6.00, 6.75 31.9 8.9 632 65 1S + 4S
245/70R19.5 16PR H 135/133M 22 4805 120 4540 120 7.50, 8.25 33.3 9.8 611 83 1S + 4S
